Unmatched Performance and Value
Specifications
Print Technology:
- Advanced PrecisionCore® TFP®
- 4-channel
- Drop-on-demand
- Inkjet printhead with ink-repelling coating technology
Ink Type:
Production Edition Ink Configuration (x2):
Droplet Technology (x2):
- Smallest droplet size: 4.2 picoliters
- Variable Droplet Technology can produce up to three different sizes per line
Maximum Print Resolution:
- 1440 x 1440 dpi; 1440 x 720 dpi; 720 x 720 dpi; 720 x 360 dpi
Print Speed:             Banner               Vinyl
- Draft:                               610 sq ft/hr         N/A
- Production:                  215 sq ft/hr         175 sq ft/hr
- Quality:                          05 sq ft/hr           140 sq ft/hr
Printer Language/Drivers:
Nozzle Configuration:
- Color and Monochrome Heads 720 nozzles per color
Catridge Fill Volume:
Ink Catridge:
Shelf Life:
- Production date or 6 months after opened
Roll Media Handling:
- Media Input: Single roll-to-roll
- Cut-sheet Size: 17"x 22" up to 64" wide
- Media Core: 2" or 3" core
- Input Roll Diameter: Up to 9.8"
- Input Roll Weight: Up to 95 lb
- Media Thickness: From 45 gsm up to 1 mm thick
- Take Up Reel: Fully automatic "wind in" or "wind out" with tension bar
- Output Roll Weight Up to 95 lb
- Media Heating System
- Pre Heater: Off or 86˚ to 122˚F
- Platen Heater: Off or 86˚ to 122˚F
- Post Heater: Off or 86˚ to 131˚F
- Independentaly controlled via control panel or front-end RIP
Printable Area and Accuracy:
- Max. Paper Width: 64"
- Min. Paper Width: 12"
- Left and Right Margins: 0.2" (0.4" total)
- Max Printable Area: 63.6""
Printer Interfaces:
- Includes as standard one HI-Speed USB 2.0 (1.1 compatible)
- One Gigabit Ethernet Port
- ONYX® GamaPrint Pro RIP Requirements
- Server Workstation
- Windows® 7, 8, Windows Vista® or Windows XP (32-bit or 64-bit) 3.2GHz Intel i7 or better 6GB memory recommended
- Client Workstation
- Macintosh 10.5+, Windows 7, 8, WIndows Vista or Windows XP (32-bit, 64-bit)
Operating Systems Supported:
- Mac® Mac OS® X, 10.8.x – 10.11.x
- Windows 10, 8.1, 7 (32-bit, 64-bit)
Weight and Dimensions (W x D x H):
- 103" x 34" x53" (2616 mm x 609 mm x 1346 mm)
- Weight: 615 lb (278 kg)
"
Acoustic Noise Level
- Aproximately 59 dB according to ISO 7779
Temperature
- Operating: 50˚ to 95˚F (10˚ to 35˚C)
- Storage: -4˚ to 104˚F (-20˚ to 40˚C)
Relative Humidity
- Operating: 20 – 80%
- Operating (recommended): 40 – 60%
- Storage: 5 to 85% (no condensation)
Electrical Requirements
- Printer requires two 110 V outlets
- Voltage: AC 100 – 120 V, AC 200 – 240 V
- Frequency: 50 – 60 Hz
- Current: 20A at AC 110 – 120 V or 10 A at AC 200 – 240 V
- Optional Dryer
- Voltage: AC 100 – 120 V, AC 200 – 240 V
- Frequency: 50 – 60 Hz
- Current: 1A at AC 110 – 120 V or 0.5 A at AC 200 – 240 V
Power Consumption
- Operating Approx. 650 W or less
- Standby Heaters On: Approx. 520 W
- Standby Heaters Off Approx. 30 W or less Power Off Less than 0.6 W or less
- Sleep Mode Less than 3.5 W
- ENERGY STAR® qualified
- Country of Origin China
