Epson SureColor S60600 Printer

List Price - $23,895

Now Only $16,895

Why should I purchase a S60600 from Equipment Zone?

The 64-inch SureColor S60600 features newly-developed Epson UltraChrome® GS3 4-color solvent ink for outstanding print quality, durability, and media compatibility. When combined with an all-new precision media feeding system and a high-performance Dual-Array PrecisionCore® TFP print head, the SureColor S60600 is capable of producing sellable quality banner at an astonishing 550 ft2 per hour, while also producing adhesive vinyl output at up to 310 ft2 per hour – making the new SureColor S60600 one the most productive sign printers ever developed.

Productive Sign Printer

A performance benchmark has been set.

Superior media compatibility

Print on virtually any media type from adhesive vinyl to banner material.

Extreme color gamut

Produce vibrant images using just four colors.

Production capacity

High-capacity ink cartridges at 700 ml per color.

Same day lamination

First solvent printers to offer same day lamination.

Consistent Color

Efficient, precise and repeatable performance with excellent image quality.

Dual PrecisionCore TFP printheads

Two one-inch wide print heads with 1440 nozzles per color.

Robust Print Head Design

Designed specifically for the high-demands of production environments.

3M MCS warranty

The most comprehensive warranty program in the signage industry is now available on all standard UltraChrome GS3 Inks.

Avery ICS Performance Guarantee

Verified and tested by one of the top media manufacturers in the world.

Includes Media Drying System at no additional cost!

Powered by Onyx

Each Surecolor S40600, S606000, and S80600 includes Onyx Gamma Print RIP Software for fast and easy production.

Specifications

Print Technology:

Dual Advanced PrecisionCore™ TFP®
8 Channel
Drop-on-demand
Inkjet printhead with ink-repelling coating technology

Ink Type:

UltraCrome GS3

Production Edition Ink Configuration (x2):

C, M, Y, K

Droplet Technology (x2):

Smallest droplet size: 4.2 picoliters
Variable Droplet Technology can produce up to three different sizes per line

Maximum Print Resolution:

1440 x 1440 dpi; 1440 x 720 dpi; 720 x 720 dpi; 720 x 360 dpi

Print Speed: Banner Vinyl

Draft: 1020 sq ft/hr N/A
Production: 550sq ft/hr 310 sq ft/hr
Quality: 310 sq ft/hrr 190 sq ft/hr

Printer Language/Drivers:

Epson ESC/P® raster

Nozzle Configuration:

720 nozzles per Color with Variable Droplet Size Minimum drop size is 5.3 picoliters

Catridge Fill Volume:

700 mL x 4 colors total

Ink Catridge:

2 years from printed

Shelf Life:

Production date or 6 months after opened

Roll Media Handling:

Media Input: Single roll-to-roll
Cut-sheet Size: 17"x 22" up to 64" wide
Media Core: 2" or 3" core
Input Roll Diameter: Up to 9.8"
Input Roll Weight: Up to 95 lb
Take Up Reel: Fully automatic "wind in" or "wind out" with tension bar
Output Roll Weight Up to 95 lb
Media Heating System

Pre Heater: Off or 86˚ to 122˚F
Platen Heater: Off or 86˚ to 122˚F
Post Heater: Off or 86˚ to 131˚F
Independentaly controlled via control panel or front-end RIP

Printable Area and Accuracy:

Max. Paper Width: 64"
Min. Paper Width: 12"
Left and Right Margins: 0.2" (0.4" total)
Max Printable Area: 63.6""

Printer Interfaces:

Includes as standard one HI-Speed USB 2.0 (1.1 compatible)
One Gigabit Ethernet Port
ONYX® GamaPrint Pro RIP Requirements
Server Workstation

Windows® 7, 8, Windows Vista® or Windows XP (32-bit or 64-bit) 3.2GHz Intel i7 or better 6GB memory recommended

Client Workstation

Macintosh 10.5+, Windows 7, 8, WIndows Vista or Windows XP (32-bit, 64-bit)

Operating Systems Supported:

Mac® Mac OS® X, 10.8.x – 10.11.x
Windows 10, 8.1, 7 (32-bit, 64-bit)

Weight and Dimensions (W x D x H):

103" x 34" x53" (2616 mm x 609 mm x 1346 mm)
Weight: 635 lbs

Acoustic Noise Level

Aproximately 59 dB according to ISO 7779

Temperature

Operating: 50˚ to 95˚F (10˚ to 35˚C)

Relative Humidity

Operating: 20 – 80%
Operating (recommended): 40 – 60%
Storage: 5 to 85% (no condensation)

Electrical Requirements

Printer requires two 110 V outlets
Voltage: AC 100 – 120 V, AC 200 – 240 V
Frequency: 50 – 60 Hz
Current: 20A at AC 110 – 120 V or 10 A at AC 200 – 240 V
Optional Dryer
Voltage: AC 100 – 120 V, AC 200 – 240 V
Frequency: 50 – 60 Hz
Current: 1A at AC 110 – 120 V or 0.5 A at AC 200 – 240 V

Power Consumption

Printer requires two 110 V outlets
Operating Approx. 650 W or less
Standby Heaters On: Approx. 520 W
Standby Heaters Off: Approx. 30 W or less
Power Off: Less than 0.6 W or less
Sleep Mode: Less than 3.5 W
ENERGY STAR® qualified
Country of Origin China

Why purchase a S60600 printer through Equipment Zone?

Equipment Zone is an authorized and trusted retailer of Epson products. We carry various Epson printers, inks & supplies at the lowest prices on the market. We stand by everything we sell, and will stand by you to make your purchase easy and assuring. Purchasing a sublimation printer is a big step, and you should feel happy in your decision. You'll be glad you purchased your printer through Equipment Zone because we are here to help you along the way. If you ever have any problems, just give us a call and you will be set up with exclusive technical support.
